3D Door
Salha 3D Door is engineered for strength, style, and durability. Made with advanced technology, it is 100% waterproof, termite-resistant, and weatherproof. Precision 3D design ensures premium aesthetics, high load-bearing capacity, smooth finish, long life, and low maintenance—perfect for modern residential and commercial spaces.
Stiffness
Flexibility
Impact Proof
Durable
3D Door IS:2202
Salha BWP 3D door is a durable product and known for its excellent quality, exceptional finish and unique dimensional stability. It is made of selected hardwood frames and accurate battens. It is evenly constructed with same species of timber that provide a longer life. BWP grade of Phenol Formaldehyde resin is used for bonding the layers. It has extra lock rail that provides great strength to the handles and knobs
Its hardwood frames provide strength for fitting of hinges and anti deviation resistance. A complete testing of 3D doors enables the company to render assured strength, safety and peace. These 3D doors are shop-floor tested and conforms to IS: 2202 specification.
•Treated Doors with Hot & cold Diffusing technology:
Salha doors are treated with Hot & Cold diffusion technology which gives it the ultimate resistant properties to hold back the product from the attacks of borers and termites. Unlike ordinary 3D door, treated Kanchan 3D doors are capable of sustaining itself from the impact of attacks, rendering greater value to the product, in terms of life and usability.
| Technical Specifications (IS:2202) | |||
|---|---|---|---|
| # | TEST | ISI REQUIREMENT | Observed Value |
| 1 | Dimension | Length, Width - ± 5 mm Thickness - ± 1 mm |
Within limits |
| 2 | Squareness | Deviation not more than 1 mm on a length of 500mm | Deviation below 1 mm |
| 3 | General Flatness | Twist, cupping, warping not to exceed 6 mm | |
| 4 | Local Planeness | Depth of deviation at any point to be less than 0.5 mm | Within limits |
| 5 | Impact Indentation Test | Depth of Indentation not to exceed 0.2 mm | Within limits |
| 6 | Edge Loading Test | Deflection of edge with max. To be less than 5 mm | Within limits |
| 7 | Shock Resistance Test | No visible defect after test | No visible defects |
| 8 | Buckling Test | Initial deflection - < 50 mm residual deflection - < 5 mm |
Within limits |
| 9 | Slamming Test | No visible damage after Test | No visible damage |
| 10 | Misuse Test | No deformation after Test | No deformation |
| 11 | Varying Humidity Test | No visible warping, twisting or de-lamination | No such defects observed |
| 12 | End Immersion Test | No de-lamination at the end | No de-lamination |
| 13 | Knife Test | Minimum Pass Standard | Excellent |
| 14 | Glue Adhesion Test | No de-lamination | No de-lamination |
| 15 | Screw Withdraw Test | Load to withdraw screw to be more than 1000 N | Load - > 1000 N |
