Laminated Door
Salha Laminated Door offers superior durability with 100% waterproof performance, termite resistance, and high-density engineered core. Built with precision bonding technology, it ensures dimensional stability, smooth finish, and long life. Ideal for homes and commercial spaces, it combines elegant design, strong load-bearing capacity, and low maintenance reliability.
They are an ideal choice for those seeking a practical and stylish alternative to traditional solid wood windows.
Stiffness
Flexibility
Impact Proof
Durable
laminated Door IS:2202
Salha BWP laminated door is a durable product and known for its excellent quality, exceptional finish and unique dimensional stability. It is made of selected hardwood frames and accurate battens. It is evenly constructed with same species of timber that provide a longer life. BWP grade of Phenol Formaldehyde resin is used for bonding the layers. It has extra lock rail that provides great strength to the handles and knobs
Its hardwood frames provide strength for fitting of hinges and anti deviation resistance. A complete testing of laminated doors enables the company to render assured strength, safety and peace. These laminated doors are shop-floor tested and conforms to IS: 2202 specification.
•Treated Doors with Hot & cold Diffusing technology:
Salha doors are treated with Hot & Cold diffusion technology which gives it the ultimate resistant properties to hold back the product from the attacks of borers and termites. Unlike ordinary laminated door, treated Kanchan laminated doors are capable of sustaining itself from the impact of attacks, rendering greater value to the product, in terms of life and usability.
| Technical Specifications (IS:2202) | |||
|---|---|---|---|
| # | TEST | ISI REQUIREMENT | Observed Value |
| 1 | Dimension | Length, Width - ± 5 mm Thickness - ± 1 mm |
Within limits |
| 2 | Squareness | Deviation not more than 1 mm on a length of 500mm | Deviation below 1 mm |
| 3 | General Flatness | Twist, cupping, warping not to exceed 6 mm | |
| 4 | Local Planeness | Depth of deviation at any point to be less than 0.5 mm | Within limits |
| 5 | Impact Indentation Test | Depth of Indentation not to exceed 0.2 mm | Within limits |
| 6 | Edge Loading Test | Deflection of edge with max. To be less than 5 mm | Within limits |
| 7 | Shock Resistance Test | No visible defect after test | No visible defects |
| 8 | Buckling Test | Initial deflection - < 50 mm residual deflection - < 5 mm |
Within limits |
| 9 | Slamming Test | No visible damage after Test | No visible damage |
| 10 | Misuse Test | No deformation after Test | No deformation |
| 11 | Varying Humidity Test | No visible warping, twisting or de-lamination | No such defects observed |
| 12 | End Immersion Test | No de-lamination at the end | No de-lamination |
| 13 | Knife Test | Minimum Pass Standard | Excellent |
| 14 | Glue Adhesion Test | No de-lamination | No de-lamination |
| 15 | Screw Withdraw Test | Load to withdraw screw to be more than 1000 N | Load - > 1000 N |
